Supported Scanners

This article will cover all laser scanners that Collage Site currently supports.

Topcon GLS-2200

Firmware Ver. 2.20 or later is required.

Firmware Ver. 2.20 or later is required.

*Upgrade Kit is required for using Collage Site with GLS-2000.

Note - When connecting Collage Site to a GTL-1200, the following on-board settings may change without notifiction:

Distance measurement unit: meter
Angle measurement unit: degree
Vertical angle display: Zenith 0 [deg]
Coordinates format: N,E,Z
Horizontal angle : Right
Beep sound: Off
These settings will need to be readjusted to your preferences if you plan on using the on-board application for scanning workflows.

For information on individual scan settings and resolution capabilities consult the manual for your scanner.

For information on individual scan settings and resolution capabilities consult the manual for your scanner.
